is it my ignition tumbler or steering lock mech?

after searching, i see there are a lot of issues with keys not turning..well add me me to the list! and now about a week after the key for my 81 240D started to intermittently not turn, now my 77 240D is doing it too.. ;(
I also am reading that replacement is far easier if the key still works, rather than the drill it out technique once its stuck.. so im gonna bite the bullet and change em..
but, im a little confused after reading though, and im not sure if i need to replace the ignition/key tumbler or if it is the steering lock mechanism that needs to be changed...
I guess I dont really know what the difference between them is, or what they do, or how to test... all i know is from time to time the key wont turn,, and i have to mess with it for sometime twisting and pounding and jiggling to get it to catch/engage and turn.
any suggestions as to narrow the problem down?
__________________
1981 240D ... 265k
1977 240D ... 265k
1977 240D ... 250k
Reply With Quote
  #2
Old 03-01-2012, 06:14 PM
Registered User

Join Date: Jan 2002
Posts: 18,352
Typically it's the lock tumbler not the ignition mechanism itself.
__________________
1977 300d 70k--sold 08
1985 300TD 185k+
1984 307d 126k--sold 8/03
1985 409d 65k--sold 06
1984 300SD 315k--daughter's car
1979 300SD 122k--sold 2/11
1999 Fuso FG Expedition Camper
1993 GMC Sierra 6.5 TD 4x4
1982 Bluebird Wanderlodge CAT 3208--Sold 2/13
Reply With Quote
  #3
Old 03-01-2012, 11:28 PM
TnBob's Avatar
Registered User

Join Date: Dec 2009
Location: Shelbyville, Tn
Posts: 1,907
With the title in your name, any MB shop with get a key that matches your existing lock setup too.
__________________
1985 300D 198K sold
1982 300D 202K
1989 300E 125K
1992 940T

"If you dont have time to do it safely, you dont have time to do it"

"The democracy will cease to exist when you take away from those who are willing to work and give to those who would not."
Reply With Quote
  #4
Old 03-30-2012, 05:41 PM
wilburtual's Avatar
240D + 240D = :)

Join Date: Oct 2010
Location: Los Angeles,CA
Posts: 192
i only have 1 key for the car, and it is really worn down, so much so that 2 locksmiths wouldnt even try to make a copy for me, saying it was too worn to copy.
i am wondering if i should try to just order a new key from the dealer for $30 and see if it is just a worn key,, rather than ordering and installing a whole new tumbler too?? although if it is the tumbler too, then i guess I have a $30 spare key
__________________
1981 240D ... 265k
1977 240D ... 265k
1977 240D ... 250k
Reply With Quote
  #5
Old 03-30-2012, 06:07 PM
Biodiesel300TD's Avatar
|3iodiesel300T|)

Join Date: Dec 2004
Location: Albany, OR
Posts: 4,845
If you're key is worn so much that a locksmith won't copy it, I'd say that's your problem. I'd get a new key from the dealer. You'll need the VIN and proof of ownership.
__________________
Andrew
'04 Jetta TDI Wagon
'82 300TD ~ Winnie ~ Sold
'77 300D ~ Sold
Reply With Quote
  #6
Old 03-30-2012, 07:30 PM
Ether's Avatar
Go S Class or go home

Join Date: Oct 2001
Location: Lawrenceville, GA
Posts: 758
Call the Classic Center and talk to Tom Hanson. He can fix you up.
__________________
Joe

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
1980 300SD - 495k miles - 'The Ambassador'
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

Former Family Members
95 C280
73 280SEL
90 300D
87 300SDL (X2)
86 560SEL
84 300D
80 300SD

Reply With Quote
  #7
Old 03-31-2012, 10:27 AM
Registered User

Join Date: May 2006
Location: Old Town, Fl
Posts: 350
If you turn the key all the way to off but don't remove it can you turn it on again? If you can, it's the steering column lock assy. If it won't turn, it's the lock cylinder. Either way do yourself a favor and get it removed ASAP. You could be one turn away from having to drill it out.
__________________
82 300SD 202K
82 300SD 233K
83 300TD 340K
82 300TD 98k euro (parts on the hoof)
85 300TD 282K
83 300TD 197K
Reply With Quote
  #8
Old 03-31-2012, 03:38 PM
Registered User

Join Date: May 2007
Location: Out in the Boonies of Hot, Dry, Dusty, Windy Nevada
Posts: 9,585
It seem there isn`t the parts for the older W123`s steering lock assy. the later style Steering lock assy. need to be used.

New style ignition tumbler in old-style 240D?

Charlie
__________________
there were three HP ratings on the OM616...

1) Not much power
2) Even less power
3) Not nearly enough power!! 240D w/auto




Anyone that thinks a 240D is slow drives too fast.

80 240D Naturally Exasperated, 4-Spd 388k DD 150mph spedo 3:58 Diff

We are advised to NOT judge ALL Muslims by the actions of a few lunatics, but we are encouraged to judge ALL gun owners by the actions of a few lunatics. Funny how that works
Reply With Quote
  #9
Old 04-05-2012, 03:08 AM
wilburtual's Avatar
240D + 240D = :)

Join Date: Oct 2010
Location: Los Angeles,CA
Posts: 192
thanks guys,
well.. now i cant get it to turn at all ;( !!! so, im gonna get a new key from the dealer and hope hope hope it is just a worn out key...!!!!
__________________
1981 240D ... 265k
1977 240D ... 265k
1977 240D ... 250k
Reply With Quote
  #10
Old 04-05-2012, 10:51 AM
Registered User

Join Date: Sep 2006
Location: san marcos, Texas
Posts: 428
If you get the new key & it still won't turn, do the "hold the key to a palm sander while turning" trick to get it turned to swap out the cylinder. It worked for me.
__________________
1982 300sd from craigslist $800 greased on one tank with NO CONVERSION in the Hot Texas Sun. (currently dead & awaiting engine damage investigation and/or longblock swap)
new daily: '03 vw 5speed jetta tdi wagon. bagged&chipped
Reply With Quote
  #11
Old 04-09-2012, 06:15 PM
wilburtual's Avatar
240D + 240D = :)

Join Date: Oct 2010
Location: Los Angeles,CA
Posts: 192
Got the new key from the dealer today...... and........ its works great!! that was for sure the problem, and after comparing the old an new key, its quite obvious so disaster averted!! after looking at my other 1977 240D key, i'm gonna go order one for him too, seems like $30 well spent!
take a look at the old and new, at first glance it looks like a totally different key !

__________________
1981 240D ... 265k
1977 240D ... 265k
1977 240D ... 250k
Reply With Quote
  #12
Old 04-09-2012, 07:02 PM
Registered User

Join Date: Mar 2009
Location: San Diego
Posts: 2,655
Quote:
Originally Posted by wilburtual View Post
Got the new key from the dealer today...... and........ its works great!! that was for sure the problem, and after comparing the old an new key, its quite obvious so disaster averted!! after looking at my other 1977 240D key, i'm gonna go order one for him too, seems like $30 well spent!
take a look at the old and new, at first glance it looks like a totally different key !

I am surprised that the old key actually WORK?
__________________
Not MBZ nor A/C trained professional but a die-hard DIY and green engineer. Use the info at your own peril. Picked up 2 Infractions because of disagreements. NOW reversed.

W124 Keyless remote, PM for details. http://www.peachparts.com/shopforum/mercedes-used-parts-sale-wanted/334620-fs-w124-chasis-keyless-remote-%2450-shipped.html

2 x 87 300SDL
1 x 87 300D
1 x 87 300TDT wagon
1 x 83 300D
1 x 84 190D ( 5 sp ) - All R134 converted + keyless entry.
Reply With Quote
  #13
Old 04-09-2012, 11:22 PM
wilburtual's Avatar
240D + 240D = :)

Join Date: Oct 2010
Location: Los Angeles,CA
Posts: 192
yeah right? it never opened the trunk lock and i thought the lock was busted, but the new key works like a charm on that one too
if anyone else is having trouble with your ignition turning, i'd recommend checking the key first! i was all set to order replacement tumbler, etc but this was waaaaay easier
__________________
1981 240D ... 265k
1977 240D ... 265k
1977 240D ... 250k
Reply With Quote
