Question How to replace bulb behind clock on '99 E-class??

Hey guys. My mom's '99 E300 has had the bulb burn out behind the clock section of her dash/cluster. I"m wondering - what's the part number or type of bulb I need, and secondly, how do I go about getting at it to replace it?? Thanks!

__________________
2004 Ram 2500 Cummins HO
2000 Jetta TDI
1999 E300 (sold)
Reply With Quote
  #2
Old 12-11-2003, 05:14 PM
Moderator

Join Date: Mar 1999
Location: Tucker, Ga USA
Posts: 12,153
The complete instrument cluster housing must be reomved.
You need special removal tools & extreme caution.
Very easy to damage the plastic cluster housing.

MB part number 910141-000000 for the bulbs. Replace at least 3, all of the ones behind the LCD displays. They stay on any time the key is on.
__________________
MERCEDES Benz Master Guild Technician (6 TIMES)
ASE Master Technician
Mercedes Benz Star Technician (2 times)
44 years foreign automotive repair
27 Years M.B. Shop foreman (dealer)
MB technical information Specialist (15 years)
190E 2.3 16V ITS SCCA race car (sold)
1986 190E 2.3 16V 2.5 (sold)
Retired Moderator
Reply With Quote
  #3
Old 12-11-2003, 05:47 PM
LightMan's Avatar
Registered User

Join Date: Feb 2002
Location: Cleveland, OH
Posts: 349
Thanks mb doc, what type of special removal tools? I was told by someone I could gently pull it out by hand, is this not true? Thanks for any tips on getting this done.
__________________
2004 Ram 2500 Cummins HO
2000 Jetta TDI
1999 E300 (sold)
Reply With Quote
  #4
Old 12-11-2003, 11:34 PM
blackmercedes's Avatar
Just a guy

Join Date: Dec 2000
Location: St. Albert, Alberta, Canada
Posts: 3,492
You cannot pull it out by hand. That is risking breaking the cluster. The tools only cost a few bucks, so spring for them.

They slide in between the cluster and the dash, and then you ease the cluster out. Your E-Class has an adjustable steering wheel which makes the job easier.

There are many many threads with instructions, so do a search and prepare for lots of info.

BTW, if you are not into the task you can have a dealer do it, and most charge an hour's labour plus the bulbs. Replace them all or you'll be pulling the cluster again soon.

I used the tools to do the bulbs on our 98 E300 and the job took about 30 minutes. I could do it quicker now, but went very slowly as it was my first time. On the C230, it takes longer as I don't have an adjustable steering wheel and have to work to get the cluster around the wheel. The dealer removes the wheel to do the job, but I can do it without.

There is a way to make your own tools using a wire coat hanger, but the MB tools work better.
