Replacing Thermostat: 1985 TD wagon (w123)

1. Anyone give me a quick heads up as to where the thermostat is located, what it's next to, etc.

2. When ordering a replacement, is it necessary to get additional gaskets? There are two offered,
Thermostat Gasket/Seal; Seal Ring with Side Hole

and

Thermostat Gasket/Seal; Thermostat Housing to Cylinder Head


Is the idea to just get both gaskets and replace, better to be safe than sorry, or are they not necessary?

Thanks a lot.
__________________
JBG
1985 TD wagon, 228k
running on grease since 3.07
AUSTIN, TEXAS
Reply With Quote
  #2
Old 05-07-2008, 06:59 PM
t walgamuth's Avatar
dieselarchitect

Join Date: Apr 2005
Location: Lafayette Indiana
Posts: 38,914
YOu shouldn't need the second one. Just follow the top hose to where it attaches to the engine. There is a bell with a nipple for the hose to attach to there. Its held on with three 10 mm bolts. put some wd40 on the bolts and very carefully jiggle them back and forth and work some oil down in the threads.

The take the stat out and put in the new one taking care to observe how the gasket and stat sits.

Reverse and refill.

Good luck

Tom W
__________________
[SIGPIC] Diesel loving autocrossing grandpa Architect. 08 Dodge 3/4 ton with Cummins & six speed; I have had about 35 benzes. I have a 39 Studebaker Coupe Express pickup in which I have had installed a 617 turbo and a five speed manual.[SIGPIC]

..I also have a 427 Cobra replica with an aluminum chassis.
Reply With Quote
  #3
Old 05-07-2008, 09:25 PM
minimike

Join Date: Oct 2007
Location: LI, NY
Posts: 320
when you try to remove any bolts.-- tighten them just a tiny cinch first then back them out. This will avoid all sorts of problems.
Reply With Quote
  #4
Old 05-08-2008, 09:48 AM
JBG JBG is offline
Registered User

Join Date: Jun 2007
Posts: 174
Thanks T, mini. From what I understand now the thermostat kit includes the necessary O-ring and the other is not necessary. Unless I hear back about this I will probably buy both anyway as they are 83 cents and I'd rather not risk it. This probably sounds ludicrous to people who have done this job before, but I have not, so I'm kind of feeling my way through it.

Thanks again!
__________________
JBG
1985 TD wagon, 228k
running on grease since 3.07
AUSTIN, TEXAS
Reply With Quote
  #5
Old 05-08-2008, 10:49 AM
Registered User

Join Date: Nov 2004
Location: Southern Maryland
Posts: 151
Heed the advice on some sort of break free on the 10mm bolts before trying to remove them. They break very easily. If you do get them out never sieze on the way back in.
Reply With Quote
  #6
Old 05-08-2008, 10:55 AM
Chad300tdt's Avatar
Benzless?

Join Date: May 2007
Location: North Wales, PA
Posts: 4,001
Now's the time to replace that 2" piece of bypass hose too.
__________________
Chad
2013 Jeep Unlimited Rubicon
OBK#44
"Pleasure in the job puts perfection in the work." - Aristotle (384-322 B.C.)

SOLD
1985 300TD - Red Dragon
1986 300SDL - Coda
1991 - 300TE
1995 - E320
1985 300CD - Gladys
2006 Nissan Pathfinder LE
1998 Acura 3.0 CL
Reply With Quote
  #7
Old 05-08-2008, 11:12 AM
JBG JBG is offline
Registered User

Join Date: Jun 2007
Posts: 174
Quote:
Originally Posted by Chad300tdt View Post
Now's the time to replace that 2" piece of bypass hose too.
Chad,

As far as I can see, that part isn't for sale (?)

(Link is broken up in 2 pieces to fit the whole thing...):

http://www.***************/search/product.aspx?sid=thhlis55lxaewmvdaceyyk45&makeid=800016@
Mercedes&modelid=1194342@300TDT&year=1985&cid=16@Cooling%20System&gid=2156@Cooling/Coolant%20Hose
__________________
JBG
1985 TD wagon, 228k
running on grease since 3.07
AUSTIN, TEXAS
Reply With Quote
  #8
Old 05-08-2008, 10:57 AM
vstech's Avatar
DD MOD, HVAC,MCP,Mac,GMAC

Join Date: Mar 2006
Location: Mount Holly, NC
Posts: 27,009
that's all that's REQUIRED to change with a tstat swap.
however, once you get in there, look very carefully at the short hose below the tstat, and see if it's in good shape. it is very annoying to get a bunch of things changed, and reassembled just to find that a simple hose is leaking forcing you to take everything back apart.
__________________
John HAUL AWAY, OR CRUSHED CARS!!! HELP ME keep the cars out of the crusher! A/C Thread
"as I ride with my a/c on... I have fond memories of sweaty oily saturdays and spewing R12 into the air. THANKS for all you do!

My drivers:
1987 190D 2.5Turbo
1987 560SL convertible
1987 190D 2.5-5SPEED!!!

1987 300TD
2005 Dodge Sprinter 2500 158"WB
1994GMC 2500 6.5Turbo truck... I had to put the ladder somewhere!
Reply With Quote
