#1
|
|||
|
|||
Small hole turns into Exhaust detailing
I have had a small hole in my exhaust manifold for a while now that was making noise. I finally found a whole exhaust manifold assembly with turbo at the junkyard for a $100
I decided to bolt the whole thing on since I had a bent fin on my turbo wheel and the new/used one doesn't have much play. I couldn't just bolt in the ugly thing, so I took part of the day yesterday day to partially disassemble, clean, wire brush, sand, brake cleaner, bench wire wheel, and paint up the new one. While the cad-plating is gone I think it turned out pretty nice. I went with an accent color of black for the waste gate shield. I also clear coated the bare metal with high temp spray to keep it from rusting/oxidizing. The flat grey is HIGH temp manifold paint. .....Now I have to clean the entire engine bay to match it Here is a side-by-side of the old one and fresh "new" one. The old one was in worse shape, but the newer one was just as oily and somewhat rusty.
__________________
1987 300TD 147,000 miles- Palomino leather interior, 1995 facelift and body cladding, E350 wheels, Rebuilt suspension and sport springs, rebuilt turbo, New Monarch injection pump and injectors....and the list goes on and on... Last edited by 1stbenznc; 02-21-2011 at 11:21 PM. |
#2
|
|||
|
|||
wow wee wow wow.
That looks brand new. Seriously, I looked at the pics first and thought, "Wow, this dude went and bought an entire new turbo setup. WTF." Anyhow, great job. Also, I just found out that those clamps on the accordion piece behind the turbo are $110/ea @ the dealer. Only 26 still left worldwide and all are in Germany... Clean those bad boys up and hang on to 'em!
__________________
'85 300TD "Puff The Magic Wagon" - Rolling Resto '19 Mazda CX-9 Signature - Wife's sled '21 Morgan 3-Wheeler P101 Edition '95 E300d - SOLD '84 300TD "Brown Betty" - Miss this one '81 240D "China Baby" - Farm grocery getter |
#3
|
||||
|
||||
Nicely done! Same here, thought it was new.
I wonder if mine has an exhaust leak?
__________________
http://farm8.staticflickr.com/7271/7...144c3fc1dc.jpg |
#4
|
||||
|
||||
Agreed, very well done.
__________________
83 SD 84 CD |
#5
|
|||
|
|||
Looks amazing, great job! Post a few pics when you get the baby installed
__________________
1983 300TD - 202k with 5 speed Getrag conversion |
#6
|
||||
|
||||
Indeed and then add your engine bay to the show your engine bay thread.
__________________
1992 W201 190E 1.8 171,000 km - Daily driver 1981 W123 300D ~ 100,000 miles / 160,000 km - project car stripped to the bone 1965 Land Rover Series 2a Station Wagon CIS recovery therapy! 1961 Volvo PV544 Bare metal rat rod-ish thing I'm here to chat about cars and to help others - I'm not here "to always be right" like an internet warrior Don't leave that there - I'll take it to bits! |
#7
|
|||
|
|||
Thanks! At least there's a place where others can appreciate it....my wife sure doesn't .
I tried to repair the hole a couple times with the super high temp exhaust repair, but it just blew it right out. I don't think the rest of the engine bay will ever look that good, but I'm doing one area at a time. When I remove something I clean and restore it the best possible. I'll post some more pics later this week.....if it warms up again...
__________________
1987 300TD 147,000 miles- Palomino leather interior, 1995 facelift and body cladding, E350 wheels, Rebuilt suspension and sport springs, rebuilt turbo, New Monarch injection pump and injectors....and the list goes on and on... |
#8
|
||||
|
||||
My new turbo didn't look that good.
__________________
Gone to the dark side - Jeff |
#9
|
|||
|
|||
TURBO
1984 300D TURBO, 157K REBUILT ENGINE METRIC 13K
NEW REBUILT TURBO $500,CORE, $400 TESTED AND BALANCE, OR BUY REBUILT KIT $100 DO A SEARCH |
#10
|
|||
|
|||
As requested - Here is the installed product from yesterday......I'm pleased with the results so far....
__________________
1987 300TD 147,000 miles- Palomino leather interior, 1995 facelift and body cladding, E350 wheels, Rebuilt suspension and sport springs, rebuilt turbo, New Monarch injection pump and injectors....and the list goes on and on... |
#11
|
||||
|
||||
Nicely done. Beautiful work!
