ML320 CDI Exposed

If anyone would like to see what the new ML320 CDI looks like under the hood, I posted a couple of photos here:

http://tinyurl.com/tune4

I would have posted them on this forum, but the tiny 65 kb maximum on attachments would not have done justice to that spilled plate of spaghetti under the plastic shroud.

__________________
1973 280SE 4.5 (Sold)
1984 LWB 280GE (Sold)
2000 G500 NMLE - "Deep Throat"
2007 ML320 CDI (Sold)
2010 Porsche Cayenne S Transsyberia TipTronic (Sold)
2010 Audi Q7 3.0 TDI (Sold and Sorely Missed)
2014 ML350 BTC
2015 Audi Q7 3.0 TDI (On Order)

Last edited by DUTCH; 12-27-2006 at 09:16 AM.
Reply With Quote
  #2
Old 01-09-2007, 11:55 PM
DR.DIESEL's Avatar
Senior Member

Join Date: Mar 2003
Location: Puget Sound, Washington St.
Posts: 522
Dutch,

Just make sure you keep the top engine cover on when driving.
It channels air at the turbo to push the heat down the firewall.
Some engineers had the paint peel off the hood during development
from too much heat and no cover.
All the new OM624 engines use this ducting.

Carefull under there. The big metal fuel lines to and from the rails and HP pump are sporting over 3000psi. If you tried to crack a line, the fuel could
hyrdo-cut your hand and wrench off clean as a water-jet tool.
Also.
The glow plugs are running 150+ volts DC plus 12-15 amps. ZAP ZAP
Lots of parts that can kick your rear if not carefull.

Enjoy your new truck!
