  #151
Old 06-23-2011, 08:37 AM
vwnate1's Avatar
Diesel Dandy

Join Date: Nov 2005
Location: Sunny So. Cal. !
Posts: 4,207
Post R12 Source

I just went to my local Old Car / Hot Rod Swap Meet & quietly asked each vendor when no one else was nearby , until one said ' sure ! how many cans do you want ? ' .

Taking the time to flush the system while it's open and apart , will also increase the amount of cold air you'll eventually get .
__________________
-Nate
1982 240D creampuff 370,000 miles
1978 300CD back from the dead&1980 300CD ~ SOLD
1984 300CD KEEPER ! 430,XXX miles
1984 Euro 300TD Fully optioned SWMBO's
1974 350SLC 4 speed stickshift SOLD & missed
Krazy Kommie Ural Motos (3)
BMW Moto R60/6 Barn Find, 8,000miles
1959 VW #113 Deuxe Beetle, 36hp engine, stock
Junk, Rust, Arthritis, Crushed Spine,Broken Neck&Back
Memories &Peace Of Mind
Reply With Quote
  #152
Old 06-23-2011, 02:40 PM
Registered User

Join Date: Jun 2008
Location: Orlando, FL
Posts: 1,269
^wanna send me some?

I'll be doing a complete flush again. That was a decently easy job last time. It even smelled nice!
Reply With Quote
  #153
Old 06-24-2011, 10:26 AM
vwnate1's Avatar
Diesel Dandy

Join Date: Nov 2005
Location: Sunny So. Cal. !
Posts: 4,207
Post R-12 Sourcing

I know you're kidding as Fla. is Geezer Old Car Central , just hit up the Auto Swaps , go early and be circumspect & polite .

If the U.S.P.S. catches it in The Post , someone will go to jail .
__________________
-Nate
1982 240D creampuff 370,000 miles
1978 300CD back from the dead&1980 300CD ~ SOLD
1984 300CD KEEPER ! 430,XXX miles
1984 Euro 300TD Fully optioned SWMBO's
1974 350SLC 4 speed stickshift SOLD & missed
Krazy Kommie Ural Motos (3)
BMW Moto R60/6 Barn Find, 8,000miles
1959 VW #113 Deuxe Beetle, 36hp engine, stock
Junk, Rust, Arthritis, Crushed Spine,Broken Neck&Back
Memories &Peace Of Mind
Reply With Quote
  #154
Old 07-10-2011, 06:17 PM
Registered User

Join Date: Jun 2008
Location: Orlando, FL
Posts: 1,269
I'm replacing my compressor with a Behr and have three seals that came with it.

The green seal fits fine, but the yellow one is slightly too short and isn't level with the green seal. The red seal is too tall.

I'm assuming that I need to use the yellow and green from what I've read, and that the inserts are not to be used.

Is this correct?
Reply With Quote
  #155
Old 07-10-2011, 07:17 PM
Yak Yak is offline
Registered User

Join Date: Aug 2009
Location: San Antonio, TX
Posts: 1,711
There's always the black one: http://autoacrepairs.com/sealing_washers.htm

My understanding is that the sealing washers should be about 1 mm higher than the body of the compressor. My old Harrison compressor used 2 black ones (3 mm each).

I replaced the Harrison with a CompressorWorks. It had holes of different depths (maybe 4 and 2 mm) and diameters. The yellow is 33.2 OD, 3 mm thick. Green, red and black are 27.9 mm OD; 5.5, 3.8 and 3, respectively.

Are the milled holes on the Behr the same depth, or different depth and diameter?
Reply With Quote
  #156
Old 07-10-2011, 08:50 PM
Registered User

Join Date: Jun 2008
Location: Orlando, FL
Posts: 1,269
^They are different depth and diameter. Only the green one fits on one of the ports, and the yellow and red fit on the other. I just want to make sure I don't have a leak because of these seals.
Reply With Quote
  #157
Old 07-11-2011, 06:35 PM
Registered User

Join Date: Jun 2008
Location: Orlando, FL
Posts: 1,269
Nevermind I figured it out. The orientation of the yellow seal made the difference and it makes a good seal against the hose on both sides.

I've got the AC system apart now, just need to flush, put it back together, get it pressure tested somewhere, and fill.

Oh did I mention that my mother called me today and said she found a half tank of R12 in my grandpas garage? She has good timing, though she did tell me she was about to just give it away
Reply With Quote
  #158
Old 07-18-2011, 02:41 PM
Registered User

Join Date: Jun 2008
Location: Orlando, FL
Posts: 1,269
Okay so I've run in to a little mystery (well I don't know what it is anyway).

I took my blower motor out because it was making some terrible noises (turned out to be a bolt in the squirrel cage ) and I noticed two vacuum lines that were not connected to anything and another that was capped off.

The black and white run to the servo, and the capped off one connects to a Y connector in the cabin. What I'm wondering is if one of those lines connects to the Y connector and the other is a vent of some sort. Or of course it could be normal and I'm just overthinking it.

Here are pictures:



Lines leading in to Servo.



Lines disconnected in cabin.



Plugged off line in Cabin.
Reply With Quote
  #159
Old 07-18-2011, 02:51 PM
compu_85's Avatar
Waiting for his Model 3..

Join Date: May 2008
Location: Springfield VA
Posts: 5,174
On the later cars the black lines are just vents, they are meant to just hang out in the dashboard and provide "clean" air for the vacuum system to "un-suck".

-J
__________________
1991 350SDL. 230,000 miles (new motor @ 150,000).

2013 Fiat 500E. 20,000 miles, 80 miles at a time.
2012 Passat TDI. 95,000 miles. More space, power, and fuel economy than the Benz
2004 Touareg V10 TDI. 150,000 miles. One of 450.
1999 Jetta TDI. 310,000 miles.
1992 Jetta ECOdiesel. 156,000 miles. 1 of 48. Sold.
1991 Jetta ECOdiesel. 430,000 miles. 1 of 700. Sold to VeeDubTDI, totaled in front of our house
Reply With Quote
  #160
Old 07-18-2011, 04:53 PM
Registered User

Join Date: Jun 2008
Location: Orlando, FL
Posts: 1,269
^Right I'm aware of that, but what about the white one? There is another white line that leads in to the center flap vacuum pod (I don't have working center vents) and there is a pod on the firewall that runs off the same line that also doesn't work. Both pods hold vacuum, so for some reason I'm not getting vacuum to them.

The servo does work. Here is the pod on the firewall that doesn't work but holds vacuum:



I'm slightly confused now, I hate dealing with vacuum stuff lol.
Reply With Quote
  #161
Old 07-18-2011, 05:45 PM
vwnate1's Avatar
Diesel Dandy

Join Date: Nov 2005
Location: Sunny So. Cal. !
Posts: 4,207
Post Mystery Servo

Quote:
Originally Posted by colincoon View Post
^Right I'm aware of that, but what about the white one? There is another white line that leads in to the center flap vacuum pod (I don't have working center vents) and there is a pod on the firewall that runs off the same line that also doesn't work. Both pods hold vacuum, so for some reason I'm not getting vacuum to them.

The servo does work. Here is the pod on the firewall that doesn't work but holds vacuum:



I'm slightly confused now, I hate dealing with vacuum stuff lol.
This one is the hot water bypass , it doesn't seem to open unless the default mode is used .
__________________
-Nate
1982 240D creampuff 370,000 miles
1978 300CD back from the dead&1980 300CD ~ SOLD
1984 300CD KEEPER ! 430,XXX miles
1984 Euro 300TD Fully optioned SWMBO's
1974 350SLC 4 speed stickshift SOLD & missed
Krazy Kommie Ural Motos (3)
BMW Moto R60/6 Barn Find, 8,000miles
1959 VW #113 Deuxe Beetle, 36hp engine, stock
Junk, Rust, Arthritis, Crushed Spine,Broken Neck&Back
Memories &Peace Of Mind
Reply With Quote
  #162
Old 07-18-2011, 09:03 PM
79Mercy's Avatar
Registered User

Join Date: Mar 2008
Location: Florida
Posts: 4,128
Your vacuum lines are correct. Those black and white ones are vents, and the black one with a cap was used to testing vacuum circuits...
__________________
1985 300TD Turbo Euro-wagon
1979 280CE 225,200 miles
1985 300D Turbo 264,000 miles
1976 240D 190,000 miles
1979 300TD 220,000

GONE but not forgotten
1976 300D 195,300 miles
1983 300D Turbo 175,000 miles

http://i42.photobucket.com/albums/e3...e485-1-2-1.jpg
Reply With Quote
  #163
Old 07-19-2011, 11:52 AM
Registered User

Join Date: Jun 2008
Location: Orlando, FL
Posts: 1,269
^ interesting. I still wonder why I don't have center vents! I'm about to just zip tie it open forever...
Reply With Quote
  #164
Old 07-19-2011, 12:01 PM
boneheaddoctor's Avatar
Senior Benz fanatic

Join Date: May 2004
Location: Hells half acre (Great Falls, Virginia)
Posts: 16,007
Center vents only operate when the temperature dial is set at the outside ambient temp.

Yeah I would have designed it different. But nobody consulted me when they did it.

I really don't like the older Chrysler Imperial based units...and I'm still not a big fan of the successors to that system either.
Reply With Quote
  #165
Old 07-19-2011, 12:16 PM
Registered User

Join Date: Jan 2002
Posts: 18,355
It's a miracle, it's a miracle. The boneheaddoctor has resurrected
__________________
1977 300d 70k--sold 08
1985 300TD 185k+
1984 307d 126k--sold 8/03
1985 409d 65k--sold 06
1984 300SD 315k--daughter's car
1979 300SD 122k--sold 2/11
1999 Fuso FG Expedition Camper
1993 GMC Sierra 6.5 TD 4x4
1982 Bluebird Wanderlodge CAT 3208--Sold 2/13
Reply With Quote
