sasquatchgeoff · #1 03-14-2010, 11:13 AM

looking at the engine bay from the front of the car: clockwise

have someone help by turning the engine over with the key. get the FSM - you will need instruction on compression testing as well as numerous other procedures in your journey. Without a manual you are depending on this forum or others for info, which won't last long.

good luck!
- Geoff

04 Diesel · #2 03-14-2010, 05:35 PM

What size socket do I need to get the injector out? When I put injector back in do I need a new cruch washer?

Found it, it is a 27mm.

sasquatchgeoff · #3 03-14-2010, 11:56 PM

Crush washer = "heat shield" - yes, must be replaced. About a buck-fifty each.

NOTE: when using the deep-well socket take extreme care not to bend or break the hose barbs for the return lines. you will regret that mistake.

04 Diesel · #4 03-15-2010, 08:15 AM

Quote:

Originally Posted by sasquatchgeoff

Crush washer = "heat shield" - yes, must be replaced. About a buck-fifty each.

NOTE: when using the deep-well socket take extreme care not to bend or break the hose barbs for the return lines. you will regret that mistake.

Yea, can I use a regular deep well socket or should I buy the special socket?

mplafleur · #5 03-15-2010, 08:33 AM

Quote:

Originally Posted by 04 Diesel

Yea, can I use a regular deep well socket or should I buy the special socket?

I've always just used a deep well socket. A 27mm I believe. The same I use for the crankshaft bolt.

04 Diesel · #6 03-15-2010, 09:26 AM

So the alda connection just stays open? Thanks for the info.

jobah · #7 03-15-2010, 09:52 AM

Alda=open
Regular deep 27 does the trick.

My 84 ran rough back, at this point, almost 15 years ago. Typically, during startup, it ran ok, then when it was warm the engine shaked. I replaced the motor mounts, the hydraulic tappets on the valves, the injectors, and even had the injector pump timing checked.

The problem turned out to be timing chain stretch and a lousy tensioner. I was told (although never verified, that the early 190D timing chain tensionsers were not well designed and had some failures). The problem had gotten so bad that the long guide upon which the tensioner acts had deep grooves almost through the black plastic.

I replaced the tensioner, the guides and the chain -- over 200kmi ago. No problems with running rough since then.

vstech · #8 03-15-2010, 10:29 AM

WAIT!!!

before attempting to remove the injectors, get the socket on there, and have the breaker bar set where you want it to loosen the injectors then HIT the handle of the wrench with your palm... DO NOT PUSH OR PULL WITH STEADY PRESSURE!!!

you're welcome!

ds190 · #9 03-15-2010, 11:43 AM

04Diesel, I have a good photocopy of the 601 factory engine manual, coil bound in two sections.

Also, two rear KYB schocks used for 15K miles.

PM sent.

04 Diesel · #10 03-15-2010, 03:01 PM

Quote:

Originally Posted by vstech

WAIT!!!

before attempting to remove the injectors, get the socket on there, and have the breaker bar set where you want it to loosen the injectors then HIT the handle of the wrench with your palm... DO NOT PUSH OR PULL WITH STEADY PRESSURE!!!

you're welcome!

Thankyou, Why am I doing it that way?

04 Diesel · #11 03-15-2010, 03:04 PM

Also I have bought two different 27mm deep well sockets and they both dont fit. What is going on? The sockets arent deep enough.

ah-kay · #12 03-15-2010, 05:06 PM

Are you working full time on this baby? You need to make a note of what is wrong with the car and prioritize the issues. I did that with my 190D, it came with many issues too. I prioritized the issues and fixed it over 6 months.

I also bought a used 190D Haynes manual from eBay for $10 which is invaluable. I only bought the gas version as it is very similar except the engine. I asked questions on the diesel engine here. Alternately you can buy the diesel version but they are normally shipped from UK and is more expensive. I checked out all the electrical issues using the manual.

BTW: If your vacuum pump pulled vacuum and held it then it should be OK. I would not remove it.

You need to buy a deep 27mm, at least 3 inches deep to remove the injectors. I think the special Mercedes socket comes with 2 openings in the middle to make allowance for the hose barb. Do not break those !!

04 Diesel · #13 03-15-2010, 06:06 PM

Quote:

Originally Posted by ah-kay

Are you working full time on this baby? You need to make a note of what is wrong with the car and prioritize the issues. I did that with my 190D, it came with many issues too. I prioritized the issues and fixed it over 6 months.

I also bought a used 190D Haynes manual from eBay for $10 which is invaluable. I only bought the gas version as it is very similar except the engine. I asked questions on the diesel engine here. Alternately you can buy the diesel version but they are normally shipped from UK and is more expensive. I checked out all the electrical issues using the manual.

BTW: If your vacuum pump pulled vacuum and held it then it should be OK. I would not remove it.

You need to buy a deep 27mm, at least 3 inches deep to remove the injectors. I think the special Mercedes socket comes with 2 openings in the middle to make allowance for the hose barb. Do not break those !!

I did buy a deep well socket, but the groves in the socket are not deep enough. I am trying to find a good manual. Thanks for the help. Yes I am working full time on this car, well allmost. I have been layed off for about three weeks and I have to do something.

ah-kay · #14 03-15-2010, 06:33 PM

Quote:

Originally Posted by 04 Diesel

I did buy a deep well socket, but the groves in the socket are not deep enough. I am trying to find a good manual. Thanks for the help. Yes I am working full time on this car, well allmost. I have been layed off for about three weeks and I have to do something.

Removing injectors?

This link has some info on the socket. A deep 1 1/16 socket would do also. I have the same car. If you need any pictures taken on the car then just PM me and I will try my best. I am not good with engine or tranny.

04 Diesel · #15 03-16-2010, 08:05 AM

Going to Sears today to look for a socket.
